Product Information
Piusi K33 Nutating Disc Flow Meters
A reliable and time served dispensing meter, for use with Diesel, Bio Diesel up to B100, and Kerosene, with an option available for higher viscosity oils including Vegetable Oil, and Lubricating Oil
The meters are supplied as standard with flow direction from left to right (looking at the meter from the front), if you wish to change the orientation to either of the other 3 possibilities, then this is simply done by removing the black cover, unscrewing and rotating the counter assembly and then replacing the black cover.
This meter displays 1 Resettable Total, and 1 Non-Resettable Cumulative Total
| Housing | Aluminium |
| Nutating Disc | Acetyl (Delrin) |
| Shaft | 316 Stainless Steel |
| Face Seal | Viton |
| Calibration Screw | Brass |
| Model Number | K33 (000553000) | K33 (000558000) |
| Suitable For | Diesel, Biodiesel | Motor Oil, Vegetable Oil |
| Display | Mechanical, 3 Digit (2.1) | Mechanical, 3 Digit (2.1) |
| Power Source | None Required | None Required |
| Minimum Flow Rate | 20 lpm | 20 lpm |
| Maximum Flow Rate | 120 lpm | 120 lpm |
| Accuracy | ±1% (User Calibration) | ±1% (User Calibration) |
| Factory Calibration | Yes | Yes |
| User Calibration | Yes | Yes |
| Inlet / Outlet Fittings | 1″ BSP Female | 1″ BSP Female |
| Maximum Operating Pressure | 10 bar / 145 PSI | 10 Bar / 145 PSI |
| Burst Pressure | 30 Bar | 30 Bar |
Download Information in PDF Document
